The NEW Walterscheid top link with integrated shock absorber

4th August 2017

GKN Walterscheid engineers developed an innovative shock absorber mechanism which is directly integrated into the hydraulic cylinder and hence does not require any additional space - This innovative technology provides for markedly increased safety and comfort.

Top Link

The new "Toplink-Feeling"

During operation, the new hydraulic top link allows for considerable extra comfort. In addition, the desired damping rate can be adjusted to individual tractor-implement combinations.




Optimised ground contact

Impact loads caused by “bouncing implements” are isolated from the tractor. This results in a markedly improved driving performance due to optimising the ground contact of the front axle.



Strong positive evidence

In addition to improved driving comfort, real-world experience also has given clear evidence of reduced component wear.



Compatible with your tractor

The new DS hydraulic top links with integrated shock absorbers are compatible and interchangeable with existing standard top links. They can be installed without additional components, and no additional space is required.





Check it out in action!



For additional information, please contact a member of our Sales Team on (01) 413 7000

Battioni Pagani - New KPS Series

30th June 2017
Battioni Logo Battioni Pump


Battioni Pagani's latest generation heavy duty pump comes with continuous operation at max vacuum thanks to a double cooling system - a combination of water & air injection.

Despite its reduced weight and size compared to current pumps with similar airflow performances available in the market, it offers excellent top performances and increased structural resistance.

Airflow: from 811 m3/h up to 1.117 m3/h

Available in M/MA/P/D/H/K/KA/GA versions

  • Heavy duty Industrial Pump
  • Double Cooling System (Water + Air Injection)
  • Integrated Air Filter
  • CPS -Crash Protection System
  • Poppet Check Valve
  • External Oil Tank
  • Compact and Light Design
  • Easy Maintenance
  •

    Have a look at the Battioni Website to see more

    Battioni Pump

    ESI Six Stream Liquid Fertiliser Nozzle

    29th March 2017
    Hypro Logo

    Choosing the Hypro ESI gives the convenience of a compact nozzle without compromising fertiliser placement. The Hypro ESI nozzle applies fertiliser through six stable streams that are offset to give precise and even fertiliser distribution when the spray from each nozzle overlaps.

    The ESI is built into a standard sized Fastcap to easily fit onto a rotating nozzle body, allowing straightforward selection and avoiding the risk of snagging and damage.

  • Six identical fluid streams distribute liquid fertiliser evenly and accurately to the root zone
  • Low pressure distribution chamber achieves high stream stability, helping to minimise leaf retention and crop scorch
  • Compact design is less prone to breakage than longer nozzles and dribble bars
  • Convenient FastCap® style is easy to fit and remove from standard nozzle holders
  • They offer cleaner, easier handling, with no loose parts
  • Large outlet holes to prevent blockage
  • Orifice constructed from durable materials for reduced wear, longer life and consistent application
  • Available in sizes 015 to 20, in ISO colours, for a wide range of application rates from 20 to 1400 l/ha


  • Apply fertiliser to dry crops with moist soil, ideally in overcast conditions with light/ moderate rain imminent.

    Avoid applying during periods of heavy frost, heavy rain, in windy conditions, after periods of drought or shortly after spraying with crop protection products.

    Download Catalogue Icon  Download ESI Nozzle Information Sheet

    IMPORTANT NOTICE - Hypress 2SC Hydraulic Hose

    1st July 2016
    2SC Hydraulic Hose

    Production volumes of Hypress 2SC hose have now surpassed that of 2SN making it more economical to produce and bringing the prices more into line. 2SC hydraulic hose has the same technical characteristics of 2SN while also offering the benefits of being a lightweight, more compact hose with improved bend radius. It can be used to replace any 2SN hose with the only physical difference being a smaller outer diameter. There is no need to change from your IMM 0022 ferrule, however you will need to adjust your after swage diameter. Please pay particular attention to the below after swage diameter information and ensure your Swaging Machine has the appropriate dies.

    IMM Ferrules
    Hose Number Description IMM Ferrule NEW
    Swage Diameter
    2SC04 1/4" 2SC Hyd. Hose 0022-04 16.7
    2SC05 5/16" 2SC Hyd. Hose 0022-05 18.7
    2SC06 3/8" 2SC Hyd.Hose 0022-06 20.1
    2SC08 1/2" 2SC Hyd. Hose 0022-08 24.3
    2SC10 5/8" 2SC Hyd. Hose 0022-10 27.7
    2SC12 3/4" 2SC Hyd. Hose 0022-12 31.4
    2SC16 1" 2SC Hyd.Hose 0022-16 39.6

    Additionally you will start to notice rebranding of all Hypress hydraulic hose to include the Interpump name. This is due to the recent acquisition of IMM Hypress by the Interpump Group. The Interpump Group is one of the leading worldwide suppliers of hydraulic products with many market leading brands in the group. You can learn more about the Interpump Group @ www.interpumpgroup.it

    Swage Label

    A Yellow label will be on any shipment of 2SC hose to remind you of the new after swage diameters.

    If you have any queries or need any further information please do not hesitate to contact your sales rep or a member of our internal sales team.

    Benefits of Hypro GuardianAIR Sprayer Nozzles

    Hypro Logo and selection of GuardianAIR Nozzles

    Guardian AIR™ spray nozzles are scientifically designed finer Air-Inclusion nozzles proven to deliver improved performance in the field. They offer a balance of excellent target coverage with reduced spray drift that can be fi ne tuned by the user. Guardian AIR™ nozzles are suitable for a wide range of crop spraying applications and are available in seven sizes.

    View our range of GuardianAIR Nozzles

    GuardianAir Nozzle

  • Better coverage with more drops per litre compared to other Air-Inclusion spray nozzles
  • Up to 75% drift reduction ratings at lower pressures to enable more spraying days
  • Good spray distribution at lower spraying pressures
  • Spray incline calculated for each nozzle to allow uniform coverage on the front and back of the plant at a wide range of speeds
  • Unique droplet structure produces droplets that stick to target
  • Excellent results at lower water volumes for faster work rates. 100 l/ha often outperforms 200 l/ha flat fan sprays in field trials
  • Proven across a wide range of combinable crop spraying applications. Recommended by Syngenta UK for applying fungicides, insecticides and some herbicides to combinable crops



  • GuardianAir Twin Nozzle

  • Produces the smallest air inclusion droplets (HGCA 2010 Nozzle Selection Chart) for more drops per litre and best spray coverage compared to other air-inclusion nozzles
  • Two 110° flat fan sprays directed at 30° inclines, one forward and the other backward
  • Twin inclined spray Improves spray coverage of taller crops, denser crop or weed canopies, small upright targets and soil clods compared to a single vertical spray
  • LERAP 2 Star , 50-75% drift reduction at lower pressures
  • New style integral FastCap™ twists smoothly onto ProFlo™ and standard EF3 nozzle holders
  • Flow metered by single pre-orifice, twin nozzle outlets are similar in size to standard flat fan
  • Dust is sealed out by the locking ring to reduce contamination when removing the nozzle from the sprayer
  • Compact design to reduce the risk of damage
  • Nozzle filter can be fitted as an option where required


  • KOYO Twice The Bearing Life

    Koyo Logo and selection of bearings

    Although already recognised as one of the world’s largest and leading bearing manufacturer and supplier, KOYO have taken major steps to increase its presence in both the Industrial OE and aftermarket business by making significant technological improvements on the standard radial bearing range.

    KOYO have developed and implemented improvements in both manufacturing processes and new steel specifications and this coupled with state of the art testing facilities have provided a much clearer comparison between actual and calculated bearing life. KOYO are proud to introduce a new dynamic load rating of 1.25 x C which now offers the longest service life (2 x calculated life) in the market today.

    GKN Walterscheid ball bushes come out on top in field test research

    Walterscheid Logo and Coupling Ball

    Extensive field tests by the renowned specialist agricultural journal, “Top Agrar”, have very clearly come out in favour of the coupling ball bushes from GKN Walterscheid. “Cheap coupling balls look just like branded products and can cost less than half but this false economy can be highly dangerous”, concludes the report in July 2014. Cheap coupling balls often have a very high carbon content making them harder but also more brittle; this makes them highly susceptible to fracture when subjected to shock loads.

    The material used for the ball bushes from GKN Walterscheid has a low carbon content on the inside. In addition, however, it contains significant quantities of chromium and manganese thus ensuring the alloy is of a considerably higher quality, compared to other products.

    Wear-resistant surface

    In contrast to the material on the inside, a relatively high carbon content is desirable for the outside of the ball bushes. A surface that is enriched with carbon in an elaborate heat treatment process is hard and correspondingly resistant. The ball bushes from GKN Walterscheid are characterised by precisely this combination of maximum wear resistance and a tough core. Ball bushes – and also ball guide cones – from GKN Walterscheid are thus extremely wear-resistant and therefore permit long-term, trouble-free operation.

    NEW Standards for Agricultural Vehicles

    Vehicle Standards 2016

    From 2016 revised vehicle standards take effect for agricultural vehicles (both new and existing) in a number of key road safety areas including Braking, Lighting & Visibility, Weights Dimensions & Coupling and Plating & Speed Rating

    Detailed information is available through the RSA website, you can follow the links below for more details.

    Vehicle Standards: Braking
    Vehicle Standards: Lighting & Visibility
    Vehicle Standards: Weights & Dimensions
    Vehicle Standards: Plating & Speed Discs

    NEW Website

    Welcome Banner

    At McHugh Components we are constantly looking to improve our service to you the customer.

    Thats why we are happy to introduce our new and improved website, we have tried to reduce the clutter while still providing all the functionality you will need. We now offer a more user friendly product search with the introduction of two new categories, Grass Parts by Brand and Tractor Parts by Brand.

    You can use your existing Login ID and Password to access the Webshop and Specials sections of the site.

    Please note due to new EU regulation in regards to privacy we no longer offer the option to save your Login ID and Password. Most browsers now offer the ability to save passwords and login details. See the links below for more details on the three most common browsers.
    Google: Chrome Browser
    Windows: Internet Explorer Browser
    Mozilla: Firefox Browser

    For additional information on navigating the site click on the Quick Guide button below or contact a member of our Sales Staff.

    Website Screen Shot with Tags

    NEW Economy Service Now Available Online

    Carton with Economy Service Label

    Although we offer a very competitive single fixed rate of carriage regardless of the amount of orders sent in a single day, we appreciate that from time to time a small single order might be all that is required.

    So we are pleased to be able to now offer a new ONLINE economy service at a reduced rate. Please contact a member of our Sales Staff or your Sales Representative for further details.

    This is only available as on online service and must be chosen by you the customer. Total order weight must be less than 15kg and a cut off time of 2.30pm.

    Each order selected for this service will be invoiced separately and not combined with any other orders for that day.

    CE Approved PTO Shafts

    PTO Shafts with CE Stamp

    As the importer into Ireland and sole agents of GKN Walterscheid the original PTO Shaft manufacturers, McHugh Components feel it is important to get on record what is supplied with all of the Walterscheid PTO Shafts.

    Each shaft comes complete with the appropriate markings and stickers as well as a maintenance booklet, which contains fitting instructions and a copy of the CE Certificate.

    This is part of the requirements under the CE Certification. With the potential dangers involved in PTO Shafts we wish to encourage all dealers and end users to be vigilant in ensuring that their PTO Shafts have the proper CE Certification and documentation when they are buying their shafts and ensure that they are fitting and maintaining their PTO Shafts to the correct standards.

    You can be sure of the correct standards if you insist on fitting GKN Walterscheid PTO Shafts, the largest manufacturer of agricultural PTO Shafts in the world. The largest manufacturers of agricultural machines across the world insist on fitting GKN Walterscheid for a reason. It is important that the trade does not cut corners with regard to safety as people's lives can be at risk.
