FRONT END LOADER VALVE
Front End Loader Valve with Floating 4th Position. Supplied c/w Attachment Kits
Type: Open Centred
Spool Set-up: 1 x D/A, 1 x D/A - floating
Ports A1, A2, B1, B2, P1, P2: 1/2"
Ports T2: 3/4"
Ports T1: 3/4" (without high pressure carry over)
High Pressure Carry Over Inlet T(co): 1/2"
Flow Rate: 90 lpm
Max Work Pressure: 250 bar
Standard RV pressure settings: 185 bar
Temperature range: -15º to +80ºC
Viscosity: 10⁄400 Cst (mm²/s)
Recommended filtering: 18/14 ISO DIS 4406
Hydraulic Fluid: Mineral oil
