MEC 8000 MECHANICAL DRIVE
Spare Parts: click here to view full list of spare parts
Mechanical drive
Maximum flow rate: 8100 lpm
Maximum RPM: 600 rpm
Maximum absolute pressure: 2.5 bar (36 psi)
Maximum relative pressure: 1.5 bar (21 psi)
Vacuum with depression valve fitted: -0.80 bar
Max vacuum: -0.94 bar
Power absorption @ 1.5 bar absolute, 540 rpm: 15 kW
Power absorption @ 1.5 bar relative, 540 rpm: 24 kW
Power absorption @ 1.5 bar absolute, 1000 rpm: 9.5 kW
Power absorption @ 1.5 bar absolute, 1000 rpm: 21 kW
Shaft EN ISO 500 Ø: 1 3/8" - 6 spline
Valve hole: 1 1/2" BSP
Nett weight: 160 kg
